Application :
Outdoor led screen applicable to outdoor stage background, large -scale road shows ,exhibitions ,concerts , conferences ,sports events ,and other outdoor lease .
Outdoor led screens Specifications:
| Pitch / mm | P4.81 |
| Pixel Density/(dots/m2) | 43264 |
| LED Configuration | 1R1G1B |
| Led Type | SMD 2121 black |
| Scan Driver | 1/13 scan |
| View angle / ° | V140/H140 |
| Average power consumption/W/M2 | 280W |
| Max power consumption/W/M2 | 560W |
| Module size/mm | 250 x 250mm |
| Module Resolution/Pixels | 52 x 52 |
| Size of cabinet/mm | 500x500mm /500 x1000mm |
| Refresh rate Hz/S | ≥2000 |
| Luminance of white balance | ≥5800nits |
| Best Viewing Distance/m | 6-30m |
| Operation of Environmental Temperature/°C | -20 ℃ ~ 50℃ |
| IP rating | IP31 |
| Working vlotage | 110-220 VAC/+/- 10% ; 50~60HZ |
| Grey scale/color | displaying colors≥16.7M(synchronized) |
| Brightness adjustment | 256 levels of each color(manually),100 levels of each color(automatically) |
| Input signal | RF,S-Video,RGB,RGBH,YUV,YC&Composition,etc |
| Control system | linsn(sending card,receiving cards and Hubs);Nova |
| Average of non-failure life | >50,000 hours |
| Life span | >100,000hours |
| Functionaless dot rate | <0.0001 |
Outdoor LED screen Features :
1 . Video function
2 . Text /image/information publish
3 . Advertising
4 . Safety function
5 . Accurate system:no error occurs.
6 . Response time :real time.
7. Reaction function
8 . Remote monitoring –details.
9 . Remote and step on powering system
10 . anti-lightening functions
11 . anti-high temperature functions
12 . System protection function The led display system has some protection functions of anti-high temperature, Anti-corrosion, pest control, waterproof, dust-proof, lightning protection, anti-static, wind, earthquake, anti-jamming systems.
13 . Set up parameter Brightness, grey scale, contrast ration, temperature parameter set up function.
14 . System extension function Video camera, HD camera, DVD, can be introduced into the system.
Outdoor Led Screen Feature :
1 . Light cabinet,more esay for carrying and installing ,saving cost.
2 . Achieving disassembly and replacement of any module in the screen within 10s,the rapid solution to any problem at the seene.
3 . Taking a separate layout instead of power cord and signal cable in the conventional screen,fast maintenance,to ensure .
4 . Product's modules,cabinet,power supply box with independent modular design,can truly achieve the function of quick maintenance for the secreen,and reduce afrer-sales costs.
led screen parts hd super thin led screen video 500 series made in china .
