Advertising Outdoor LED Screens Full Color Video Billboard P5 Waterproof IP65 Module

Shenzhen Vios Electronic Technology Co., Ltd
Contact Now

Advertising Outdoor LED Screens Full Color Video Billboard P5 Waterproof IP65 Module

  • 1
  • 2
  • 3

Brand Name : Viso

Model Number : PH5

Certification : UL CE ROHS ISO ETL SGS SAA Fcc EMC

Place of Origin : China

MOQ : 1 Square Meter

Price : Negotiation

Payment Terms : L/C T/T Western Union Paypal Credit Card, MoneyGram, VISA

Supply Ability : 6,000 square meters per month

Delivery Time : 4-6 work days

Packaging Details : Wooden box or Flight case

Module Size : 320 mm x 160 mm

Package Mode : SMD 2727

Pixel Density : 40000 dot / m2

Pixel Configuration : 1R1G1B

Best viewing distance : 5 - 50 M

Brightness : >6500 cd / sqm

Driving method : 1 / 8 Scan

IP grade : IP65

Port Type : HUB75

Warranty : 5 Years

Contact Now


Full hd led tv Advertising Outdoor LED Screens Full Color Video Billboard P5 Waterproof IP65 Module

Technical Specifications
NO Product name outdoor P5 led display
1 Pixel Pitch(mm) 5mm
2 Pixel configuration 1R1G1B/
3 Pixel density 40000 dots/m2
4 Brightness 6500cd/m2
5 Module size(W*H) 320mm * 160mm
6 Module Resolution (W*H) 64 dots x 32dots
7 Module weight 500g
8 Cabinet size (W*H) 640mm×640mm
9 Drive IC MBI5124
10 Drive mode 1/8scan
11 Viewing Angle(V/H) 140ºC
12 Grey Scale 65536 degree
13 Life time >100,000 Hours (50%)
14 MTBF >50,000 Hours
15 Operating Voltage AC110V/220V±10%
17 Screen Power Consumption Max: 680w/m2; Average:220w/m2
18 Input Power Frequency 50/60Hz
19 Operating temperature -30--60ºC
20 Humidity 10%-95%
21 Refresh Rate ≥1200HZ
22 Control Method Synchronized with computer monitor
23 Color Temperature 6500K-9500K
24 LED control system LINSN,Nova-star,Colorlight is selectable
25 Control Distance 100 m (no repeating); Optical fiber transmission: 500m- 15km
26 Accepting signal with video processor PAL/NTSC/SECAM,S-Video;VGA;RGB;Composite Video;SDI
27 Systems Operating Platform Windows Xp / Windows 7 / windows 8 /8.1 / windows 10

Product Introduction :


1 . High brightness, big viewing angle with SMD3535 led lamp, brightness about more than 6500cd / m² ,perfectly suited for outdoor environment, 3 in 1 led lamp blending well, especially good color reproduction and viewing angle, giving the visual sense and feel much more than traditional outdoor DIP full color display.


2 . The total amount of heat reduced. Using energy-saving (low constant current from the control point), high efficiency constant current chip;Using high brightness and high efficiency of LED lamps;


3 . The automated process.All using SMD process, fully automated machine operation, reducing human error and damage and improves reliability.


4 . Low failure rate. Using sophisticated type of material, in terms of testing: instrument light intensity distribution, it is a direct measurement of the LED lamp light intensity, viewing angle, wavelength, and other optical properties; aging test LED lamps attenuation; an IC testing stand, strict control the quality of the IC. High-temperature aging at the end of the production process and cabinet vibration test, good control of Weld and other issues.


5 . Cabinet Select:Die casting Aluminum; Aluminum profile cabinet; Brushed aluminum cabinet; water proof cabinet . Fast locks and assembling pins, flatness and seamless are greatly increased, less than 0.01mm , easy to install and dismantle .Seamless connection, less than 0.1mm between 2 cabinet.

Feature:


1 . With good lightening accordance and no mosaic


2 . Can play different formats of image files, flash, WAV/MIDI, video signal from
TV, video signal from video and other equipment


3 . Different video frequency can be changed freely at the same time, and the image
can be enlarged and reduced


4 . High brightness, and can be adjustable, meets the need of changing requirement
of customer in environment


5 . Usually use for advertising outdoor

Application and Market :


1. Application


Widely use in stadiums, advertisement, banks, securities exchange, stations, shopping malls, postal offices, schools, restaurants, entertainment, enterprises, highway etc


2. Market:


North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, MID East, Eastern Asia, Western Europe

Packaging & Shipping :


1 . Packaging : Paper carton, Antishaking wooden box, flight cases or according to your request to ensure safety during transportation.

2 . Shipping : 3-15 days after receiving your payment

Advertising Outdoor LED Screens Full Color Video Billboard P5 Waterproof IP65 Module
