Energy Saving Indoor LED Video Wall Panels SMD1010 Full Color With Thin Cabinet

Shenzhen Vios Electronic Technology Co., Ltd
Contact Now

Energy Saving Indoor LED Video Wall Panels SMD1010 Full Color With Thin Cabinet

Brand Name : Viso

Model Number : PH3

Certification : UL CE ROHS ISO ETL SGS SAA Fcc EMC

Place of Origin : China

MOQ : 1 Square Meter

Price : Negotiation

Payment Terms : L/C T/T Western Union Paypal Credit Card, MoneyGram, VISA

Supply Ability : 5,000 square meters per month

Delivery Time : 4-6 work days

Packaging Details : Wooden box or Flight case

module size : 192mm× 192mm

Pixel density : 11,1111 dots / sqm

Module pixels(W*H) : 64 dots × 64 dots

Pixel configuration : 1Red 1Green 1Blue

LED lamp type : SMD2121

CabineColor scalet : 576mm×576mm

Module size(W*H) : 192 mm(width)×192 mm(height)

Contact Now

Energy Saving Indoor Small Pitch LED Display SMD1010 Full Color With Thin Cabinet


Pixel 3mm Music Concert Stage LED Screens With 1 / 32 Scan , 64 Dots × 64 Dots

Specification:

Model

P3 LED display for rental indoor

Pixel pitch

3mm

Pixel density

11,1111 dots / sqm

Module size(W*H)

192 mm(width)×192 mm(height)

Module pixels(W*H)

64 dots×64 dots

Pixel configuration

1Red 1Green 1Blue

Drive mode

constant current driving 1 / 32 scan

LED lamp type

SMD2121

Cabinet size(W*H)

576mm×576mm

Color scale

65,536 degree

View angle(H/V)

140 / 120 degree

Brightness (White balance)

about 1300cd / sqm.

Power consumption(one cabinet)

Max:300W / cabinet , Average: 120W / cabinet

Inputting Voltage

86-264 VAC 47--63Hz

Net weight

10Kg / cabinet

Operating temperature

-30°C----+60°C

Operating humidity

10%—95%RH

Life time

≥100,000hours

MTBF

5,000 hours

Whole Display Flatness

≤0.5mm Juncture

Frame frequency

25-60 Hz / s

Refresh rate

≥2000Hz / s

Control distance

100m (without repeater), single mode fiber:20km, multi mode fiber:
500m

LED control system

LINSN,Nova-star,Colorlight is selectable

Operating system

Windows Xp / Windows 7 / windows 8 /8.1 / windows 10

Protection grade

IP31

Maintenance way

Rear Access



Application:

Shopping Malls

Music Venues and Concerts

Big office

Theater and Arts

TV Shows

Car Shows

Energy Saving Indoor LED Video Wall Panels SMD1010 Full Color With Thin Cabinet
